Transmission Gear Ratio Chart



Click here to return to our Transmission Page…
Click here to return to our Ring & Pinion Page…

TransDate Range1st2nd3rd4th5th6thRevT/CaseOutput SplineT/C ShiftNotes
L431979-803.6702.1101.4511.000  4.180Gear21-splineTop20.875", side shifting
L451981-823.9282.3331.4511.000  4.743Gear21-splineTop20.875" long
L501981-823.9282.3331.4511.0000.851 4.743Gear21-splineTop20.875" long, 75x19mm input bearing
L5219833.9282.3331.4511.0000.851 4.743Gear21-splineTop20.875" long, 80x20mm input bearing
G521984-863.9282.3331.4511.0000.851 4.743Gear21-splineForward25.5" long, 80x20mm open-face input bearing
G541986-883.9282.3331.4511.0000.851 4.743Gear21-splineForward25.5" long, 80x23mm sealed input bearing
G581989-953.9282.1421.3971.0000.851 4.743Chain26-splineForward25.5" long, front vacuum disconnect
W551984-883.5662.0561.3841.0000.850 4.091   2WD Applications
W56-A19853.9542.1411.3841.0000.850 4.091Gear21-splineTop25.5" long, Aluminum Center Section
W56-B1986-883.9542.1411.3841.0000.850 4.091Gear21-splineTop25.5" long
W56-C1989-913.9542.1411.3841.0000.850 4.091Gear21-splineForward25.5" long
W56-D19923.9542.1411.3841.0000.850 4.091Gear21-splineForward25.5" long
W56-E1993-953.9542.1411.3841.0000.850 4.091Gear21-splineForward25.5" long
W581982-893.2851.8941.2751.0000.783 3.768Chain26-splineTop25.5" long
W591995-043.9542.1411.2751.0000.850 4.091Chain26-splineTop25.5" long
R150F1988-913.8302.0621.4361.0000.838 4.220Chain23-splineTop
R150F1992-953.8302.0621.4361.0000.838 4.220Chain23-splineTop
R150F1995-043.8302.0621.4361.0000.838 4.220Chain23-splineTop
R151F1986-874.3132.3301.4361.0000.838 4.220Gear23-splineForward22R-TE Turbo
MAR5151986-045.152.7401.9301.0000.830   23-spline
R1541986-923.2501.9551.3101.0000.753     Toyota Supra Turbo
R155F2005+3.952.061.441.000.81 4.22Chain23-splineTop2TR-FE 2.7 liter
RA60F2005-20154.1712.1901.4881.1931.0000.8493.607Chain19-splineTop26-1/4" long, Tacoma
RA61F2006-20144.1712.1901.4881.1931.0000.799Chain19-splineTopFJ Cruiser
RC62F2016-20233.982.021.321.000.850.713.39Chain19-splineTop27-15/16" long, Tacoma
A340F1985-042.8041.5311.0000.705  2.393   4spd Automatic
A750F2005-20153.5202.0421.4001.0000.716 3.224   5spd Tacoma Automatic
AC60F2016-20233.602.091.491.000.690.583.73   6spd Tacoma Automatic
AX51984-023.922.331.441.0000.85 4.74 21-spline Cherokee, Comanche, and Wranglers
AX151989-99?3.832.331.441.0000.79 4.22 23-spline Cherokee, Comanche, and Wranglers
