This is a Genuine Toyota 3VZ Flywheel Bolt. It fits all 1988-95 3-liter 3VZ-E engines.

Please see the included Factory Service Manual instructions above. Apply adhesive, such as Permatex No.2 or Permatex High Tack onto the threads before assembly. Torque to 65 lb-ft in the sequential order shown. We recommend the following three passes: 20 lb-ft, then 40 lb-ft, then finally 65 lb-ft.

Dimensions: 32.5mm long X 10mm diameter X 1.25mm thread pitch. The entire bolt measures 42mm in length.

Sold individually, 8 required per engine.
